High Productivity Hello Panda Chocolate Injection Biscuit Production Line

Product Categories
Skywin Foodstuff Machinery Co., Ltd.
Contact Now

High Productivity Hello Panda Chocolate Injection Biscuit Production Line

Brand Name : Skywin

Certification : CE

Place of Origin : Guangdong, China

MOQ : 1 Set/Sets

Price : $100,000.00 - $600,000.00 / Set

Supply Ability : 3 Set/Sets per Quarter wafer biscuit making production line

Packaging Details : WOODEN CASE for Export Standard Suitable for Seaworthy

Condition : New

After Warranty Service : Video technical support, Online support

Video outgoing-inspection : Provided

Marketing Type : Hot Product 2020

Warranty of core components : 1 Year

Core Components : PLC, Engine, Bearing, Gearbox, Motor, Pressure vessel, Gear, Pump

Voltage : 380V/50Hz

Power : 120KW

Dimension(L*W*H) : 1900*1350*800mm

Weight : 1450KGS

Warranty : 1 Year

After-sales Service Provided : Online support

Application fields : Snack food factory, Beverage Factory

Output product name : bear/ panda biscuit

Key Selling Points : High Productivity

Capacity : 100-1500kg/h

Biscuit Type : bear/cracker/hard

Materials : Stainless steel 304#

Transducer : SIEMENS

control : SIEMENS PLC

Conveyor belt : Cotton and PU

bearing : Chinese famous brand and NSK Brand

Gearbox : SEW brand or Chinese famous Brand GUOTAI

Function : Multi-function

Air cylinder : AirTAC Brand

Port : GUAGNZHOU PORT / SHENZHEN PORT/ SHUNDE PORT

Contact Now

Product Description
Machine component:
1. Gauge roller diameter 300-350mm, Feeding roller diameter 350mm
2. Schneider inverter&transducer and PLC touch screen control
3. Schneider electronic from France
4. Main driver by Chinese Famous Guomao Brand motor & gearbox
5. Main bearing use NSK from Japan
6. AirTAC Penumatic cylinder for belt tension and deflecting adjustment
7. PU belt from Heland Ammeraal Beltech brand 1.2-1.5mm thickness
8. Main machines 304 Stainless steel cover, thickness 1.2-1.5mm; oven cover 304 stainless
9. Air cylinder use AirTAC
10. All power-roller for convey belt use food grade, oil-resistance rubber roller
Specification
item
value
Type
SK-400/600/800/1000/1200/1500
Key Selling Points
High productivity
Capacity
100-1500kg/h
Biscuit Type
bear/cracker/hard
Materials
Stainless steel 304#
Transducer
SIEMENS PLC control
Conveyor belt
Cotton and PU
bearing
Chinese famous brand and NSK Brand
Gearbox
SEW brand or Chinese famous Brand GUOTAI
Function
Multi-function
Air cylinder
AirTAC Brand

High Productivity Hello Panda Chocolate Injection Biscuit Production Line
High Productivity Hello Panda Chocolate Injection Biscuit Production Line
Process
High Productivity Hello Panda Chocolate Injection Biscuit Production Line
Horizontal Dough Mixer and dough Tub
*Horizontal dough mixer for soft biscuit and hard biscuit dough
*Speed from 25r/min to Max. Speed60r/min, frequency speed
*Germany Famous brand SEW motor & gearbox
*Full stainless steel 304#
with one Dough Tub capacity 150kgs.
*Tub thickness 5mm and 8mm.
*Newest design touch screen Siemens PLC control system.
High Productivity Hello Panda Chocolate Injection Biscuit Production Line
Automatic dough tipper and feeding system
This system has included one small dough truck, automatic tipper, one dough cutting and transport machine, and soft dough conveyor belt.
*Gearbox use GUOMAO BRAND brand, bevel wheel with high drive efficiency,low noise and work stability and so on.
*GUOMAO BRAND motor, High efficiency, low noise and long using life and so on.
*PU conveyor belt with baffle groove to carry small pieces dough, belt thickness 1.5mm, rubber covered main roll.
*Cutting controlled by air pneumatic, AirTac air cylinder. conveying belt support splint use 304 Stainless steel
*Main driver use direct drive, NSK bearing from Japan
*Electric control: All driving speed controlled by frequency Conversion, Transducer and *Electronic element use Schneider brand
High Productivity Hello Panda Chocolate Injection Biscuit Production Line
Three-roll Combination Sheeter
*Double groove feeding rollers
*PU conveyor belt, thickness 1mm
*Gearbox use GUOMAO BRAND brand, bevel
wheel with high drive efficiency, low noise and work stability and so on.
*Motor: GUOMAO BRAND brand, high efficiency, low noise and long using life and so on.
*Groove rolls diameter 350mm, sheeting rolls diameter 350mm, high quality cooled rigidity cast iron rolls,
High Productivity Hello Panda Chocolate Injection Biscuit Production Line
Horizontal Laminator
Stainless steel, Support roller, transition scraper covered hard chrome
Main driver use double rows chain, NSK bearing from Japan
Electric control: All driving speed controlled by frequency conversion
Transducer and Electronic element use Schneider brand
Laminating width 1000mm, 4-12layers, sheeting dough thickness 0-10mm, included crisp spreader machine Power: 4.5KW,
Dimension: 2620x1330x2080mm, Weight: 2500kg
High Productivity Hello Panda Chocolate Injection Biscuit Production Line
Gauge Roll Sheeting Group (1st, 2nd and 3rd)
*Gearbox use GUOMAO BRAND brand, bevel wheel with high drive efficiency, low noise and work stability and so on. Motor:
*GUOMAO BRAND brand, high efficiency, low noise and long using life and so on.
*First Gauge roll and Second Gauge roll Sheeting rolls
diameter 300mm, Third Gauge roll Sheeting rolls diameter 350mm,
*High quality alloy steel Sheeting rolls and Conveyor belt controlled by one motor
High Productivity Hello Panda Chocolate Injection Biscuit Production Line
Rotary Cutter(for hard biscuit)
*Embossing in one roller and cutting in one roller, PU conveyor belt, thickness 1mm, *Gearbox use GUOMAO BRAND brand, bevel wheel with high drive efficiency, low noise and work stability and so on. Motor *GUOMAO BRAND brand, high efficiency, low noise and long using life and so on.
*Two rubber rolls diameter 220mm for cutting, two rubber rolls diameter 160mm for cotton conveyor belt.

High Productivity Hello Panda Chocolate Injection Biscuit Production Line
Separation Machine
*Automatic Air pneumatic separate device, Up and Down controlled by separate motor, rubber covered main drive roll
*Transition scraper covered hard chrome, Scrap tray and cover made by 304 stainless
steel, 1.2mm thickness
* Main driver use chain drive, NSK bearing from Japan, Electric control: All driving speed controlled by frequency conversion *Transducer and Electronic element use *Schneider brand Working width 1000mm, sheeting dough thickness 0-20mm
*Power: 2.5KW
* Dimension: 1860x1320x1020mm
*Total weight: 650kg
High Productivity Hello Panda Chocolate Injection Biscuit Production Line
Enter stove machine
The sprinkler and recycle tray was installed on front of enter stove machine, the back is enter oven part.
*Cotton conveyor belt, thickness 1.5mm
*The belt tension and deflection adjusted by Air pneumatic
* Air cylinder AirTAC brand
*Gearbox use GUOMAO BRAND brand, bevel wheel with high drive efficiency, low noise and work stability and so on.
*Motor: GUOMAO BRAND brand, high efficiency, low noise and long using life and so on.
High Productivity Hello Panda Chocolate Injection Biscuit Production Line
Tunnel oven
Electric baking oven is used electricity as energy. It’s high efficiency, long usage, easy maintenance.
Gas baking oven is used natural gas as energy. It’s more scientific and safe, high efficiency rapid heating, save energy, clean and simple operation.
Model
length of oven(30-60m)
Capacity
400mm
16-40m
100-200kgs
600mm
50m
200-400kgs
800mm
50-60m
400-600kgs
1000mm
50-60m
600-800kgs
1200mm
65m
800-1000kgs
Biscuit stacking machine
One is Star wheel structure, it is composed by transition conveyor, divided biscuits in order rows and stacking, total two conveyor belts.
The other is Panny Biscuit stacker, usually it combined by 3 units of different speed conveyors, the speed from fast to slow,through discrepancy speed to make the biscuits lay down as lines, to easy transport to packaging machine
Sample
High Productivity Hello Panda Chocolate Injection Biscuit Production Line

Panda/Bear shape of biscuit
The shape of biscuit depend on you
High Productivity Hello Panda Chocolate Injection Biscuit Production Line

Hard biscuit rotary cutter mould
If you want to make panda and hard biscuit or other special shape of biscuit just change the mould. We also can design the mould for you as per your detail.
Company Introduction
High Productivity Hello Panda Chocolate Injection Biscuit Production Line
SKYWIN Food Machinery Group Company was Founded in 2010,which is lotated in Beijiao, Shunde, Foshan, Guangdong, CHINA Foshan City is stainless steel Birthplace.
Skywin Group has two factories, one is for Large Biscuit & Cookies & Wafer production line, one is for Automatic Biscuit sandwiching machine with Packing system. We have more than 60 professional staffs to match delivery time, base on “International Quality, Competitive Price”.
After Sales Service
High Productivity Hello Panda Chocolate Injection Biscuit Production Line
Packing&Shipping
High Productivity Hello Panda Chocolate Injection Biscuit Production Line
Step 1: Mechanical surface coated with preservative solution (to protect stainless steel).
Step 2: The plastic cushion packing machine (prevent bump).
Step 3: Plastic film packaging (to prevent ventilation).
Step 4: Wooden case / frame packaging (easy to transport).
Step 5: Tie the bandage outside of the wooden case (reinforcement overall).
FAQ
High Productivity Hello Panda Chocolate Injection Biscuit Production Line
